China New Developed Hot Sale Compound Epoxy Resin Cable Trays with ISO9001 Certificates
| FOB Price: | 0.52 - 2.31 USD/Meter |
|---|---|
| Supply Ability: | 3,000,000 Meter/Meters per Week |
| Shipping: | by sea or by air , 30 days after deposit, xingang,china port |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hebei in China |
| Packaging Details: | carton or pallet packing outside to containers |
Quick Details
- Application: Epoxy resin cable trays are widely used in oil refining, chemical, tex
- Number of Conductors: no
- Jacket: FRP
- Insulation Material: Rubber
- Model Number: 0145
- Brand Name: wj
- sturdy structure: good non-corrosive
- flame retarded property: Withstand strong wind
- Electrically non-conductive: Resist insect damage
- Never fade and corrode: Low water absorption
- cut into ideal length: installed vertically and horizontally.
- Low maintenance: Long life expectancy with over thirty years
Specifications
Epoxy Resin Cable Trays are
suitable choices for highly corrosive environment. According to the
structure, epoxy resin cable trays can be classified into channel type,
ladder type, perforated type, large span cable type. Epoxy resin cable
trays have highly corrosion resistance, fire retardant and strong
anti-aging properties widely used in industry plants.
Features:
- Epoxy resin cable trays have sturdy structure to lay cables.
- Epoxy resin material has good non-corrosive, flame retarded property.
- Withstand strong wind, rain, ice and adapt to harsh natural environment.
- Electrically non-conductive.
- Resist insect damage.
- Never fade and corrode.
- Low water absorption.
- Can be easily cut into ideal length.
- Epoxy resin cable trays can be installed vertically and horizontally.
- Low maintenance.
- Long life expectancy with over thirty years.
| Item | Model | W(mm) | H (mm) | L (mm) |
| Epoxy Resin Cable Tray | QWX-ER-01 | 100 | 50 | 350 |
| 100 | 500 | |||
| 150 | 100 | 550 | ||
| 150 | ||||
| 200 | 100 | 600 | ||
| 150 | ||||
| 200 | ||||
| 300 | 100 | 700 | ||
| 150 | ||||
| 200 | ||||
| 400 | 100 | 800 | ||
| 150 | ||||
| 200 | ||||
| 500 | 100 | 900 | ||
| 150 | ||||
| 200 | ||||
| 600 | 100 | 1000 | ||
| 150 | ||||
| 200 | ||||
| 800 | 100 | 1200 | ||
| 150 | ||||
| 200 |
Specification:
- Material: epoxy resin material.
- Epoxy resin thickness: 1.5mm - 2.0mm.
- Length: 2000mm - 6000mm.
- Width: 100mm, 150mm, 200mm, 400mm, 800mm, 1200mm.
- Depth of rail: 50mm, 100mm, 150mm, 200mm.
- Structure: ladder type, perforated type, channel type, large span type.
Applications:
Epoxy
resin cable trays are widely used in oil refining, chemical, textile,
mechanical, metallurgic, power, TV and broadcasting industries as well
as underground facilities, etc.
