Home >Products Catalog > Automatic Sheet to Sheet Embossing Machine Model YW-E

Automatic Sheet to Sheet Embossing Machine Model YW-E

Shipping:	30% advance payment be paid by TT, balance paymen shall be paid before shipment
Payment Terms:	L/C, T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Zhejiang in China
Packaging Details:	Standard export package

Quick Details

Type: Embossing Machine
After-sales Service Provided: Engineers available to service machinery overseas
Certification: CE
Weight: depends on machine size
Dimension(L*W*H): depends on machine size
Power: depends on machine size
Voltage: 380V/50HZ/3 PHASE (the voltage can change with surcharge)
Driven Type: Hydraulic
Packaging Material: Wood,Plywood
Packaging Type: Cartons
Application: Machinery & Hardware
Condition: New

Specifications

PRODUCT DESCRIPTION

The automatic paper embossing machine with the functions like automatic feeding & auto picker collecting paper was developed at the basis of the original embossing machine with manual feeding and collecting, Full automatic control in processing. Adopted frequency governor, automatic hydraulic system and pneumatic blade, it is characterized by controllable speed, double-sheet control, automatic counting, etc. Its average can range form 3000~5000pc/h. It is applied to embossing the sheet surfaces of batches like packing products, playing cards, gift cards, golden and silver card paper, etc.

Optional collector:

-Auto vibrating collector

-Manual collecting table

MAIN TECHNICAL INDEX

Model	YW-720E	YW-920E
Max embossing speed	80 m/min	80 m/min
Max embossing width	680mm	880mm
Paper range	> 160 g/m²	> 160 g/m²
Operation pressure	2-10 Mpa	2-10 Mpa
Main motor pressure	14 kw	15 kw
Vacuum pressure	0.06 Mpa	0.06 Mpa
Air source pressure	1.8-1.0 Mpa	1.8-1.0 Mpa
Overall dimension(LxWxH)	4800x1500x1800 mm	4800x1700x1800 mm
Machine weight	2800 kgs	3500 kgs

Model	YW-1150E	YW-1300E
Max embossing speed	80m/min	80 m/min
Max embossing width	1000mm	1180 mm
Paper range	> 160 g/m²	> 160 g/m²
Operation pressure	2-10 Mpa	2-10 Mpa
Main motor pressure	16 kw	18 kw
Vacuum pressure	0.06 Mpa	0.06 Mpa
Air source pressure	1.8-1.0 Mpa	1.8-1.0 Mpa
Overall dimension(LxWxH)	4800x1800x1800 mm	4800x2000x1800 mm
Machine weight	4200kgs	5000kgs
